HORIZONTAL PARTING FLASKLESS AUTOMATIC MOLDING MACHINE

HORIZONTAL PARTING FLASKLESS AUTOMATIC MOLDING MACHINE

Specification

Model HC5040 HC5545 HC6050 HC6550
Sand mold size(mm) 500*400 550*450 600*500 650*550
Sand mold height(mm) top:110/170
bottom:100/170
top:110/180
bottom:100/180
top:110/200
bottom:100/200
top:110/200
bottom:100/200
Molding type Pneumatic shooting sand +hydraulic compaction



Productivity(s/mold) 30-40 30-40 30-40 30-40
Air consumption 1m3 1.2m3 1.4m3 1.6m3
Pneumatic pressure 0.7Mpa 0.7Mpa 0.7Mpa 0.7Mpa
Power(kw) 16 16 16 19
Hydraulic pressure 13Mpa 13Mpa 13Mpa 13Mpa
Overall size(mm) 3750*1960*2980 3850*2060*3000 3950*2200*3100 4050*2300*3200
We promise:Sand box is ductile cast iron;Air TAC pneumatic components;Yuken hydraulic components;

MITSUBISHI electric control system

Remark:we can design and manufacture according to clients requirements.





Model HC7060 HC7565 HC8070
Sand mold size(mm) 700*600



750*650 800*700
Sand mold height(mm) top:110/230
bottom:120/230
top:110/230
bottom:120/230
top:130/230
bottom:130/230
Molding type Pneumatic shooting sand +hydraulic compaction



Productivity(s/mold) 35-45 35-45 40-50
Air consumption 2m3 2.3m3 2.7m3
Pneumatic pressure 0.7Mpa 0.7Mpa 0.7Mpa
Power(kw) 19 19 34
Hydraulic pressure 13Mpa 13Mpa 13Mpa
Overall size(mm) 4200*2400*3300 4300*2500*3400 4400*2600*3500
We promise:Sand box is ductile cast iron;Air TAC pneumatic components;Yuken hydraulic components;

MITSUBISHI electric control system

Remark:we can design and manufacture according to clients requirements.
